机座号Frame size: 6~355 功率 Power: 12^*315kW 工作制 Working system: S1 绝缘等级 Protection grade: F
YE3系列产品特点
Features Of YE3-series Products
YE3系列电动机是Y-YE3系列的改进设计，产品性能全面与国际IEC标准接轨，具有结构新颖、造型大方美观、振动小、噪音低、耐热和防护等级提高等特点具有高效、节能，达到现代国际先进水平，是Y-Y2系列的换代产品。
YE3 series three-phase asynchronous motor is the improvement of Y series. The terminal box is located on the top of motor, the motor structure is compact and the appearance is attractive, all in conformity with IEC standards.The motor have some good feature, such as high effecient, energy-saving, high starting torque and easy maintenance etc.
技术参教 Technical Data
| 型号 | 功率 | 额定电流A | 转速 | 效率％ | 功率因数 |
| Type | KW | Current | r/min | Eff. | Power Factor |
| 同步转速 Synchronous speed3000 r/min | |||||
| YE3-63M1-2 | 0.18 | 0.50 | 2720 | 65.0 | 0.80 |
| YE3-63M2-2 | 0.25 | 0.65 | 2720 | 68.0 | 0.81 |
| YE3-71M1-2 | 0.37 | 0.96 | 2740 | 70.0 | 0.81 |
| YE3-71M2-2 | 0.55 | 1.30 | 2740 | 73.0 | 0.82 |
| YE3-80M1-2 | 0.75 | 1.72 | 2845 | 75.0 | 0.83 |
| YE3-80M2-2 | 1.1 | 2.44 | 2845 | 77.0 | 0.84 |
| YE3-90S-2 | 1.5 | 3.29 | 2840 | 79.0 | 0.84 |
| YE3-90L-2 | 2.2 | 4.61 | 2840 | 81.0 | 0.85 |
| YE3-100L-2 | 3 | 6.1 | 2860 | 83.0 | 0.87 |
| YE3-112M-2 | 4 | 7.78 | 2880 | 85.0 | 0.88 |
| YE3-132S1-2 | 5.5 | 10.2 | 2900 | 86.0 | 0.88 |
| YE3-132S2-2 | 7.5 | 14.0 | 2900 | 87.0 | 0.88 |
技术参数 Technical Data
| 型号 | 功率 | 额定电流A | 转速 | 效率％ | 功率因数 |
| Type | KW | Current | r/mln | Eft. | Power Factor |
| 同步转速 Synchronous speed 1 500 r/min | |||||
| YE3-63M1-4 | 0.12 | 0.41 | 1310 | 57.0 | 0.72 |
| YE3-63M2-4 | 0.18 | 0.59 | 1310 | 60.0 | 0.73 |
| YE3-71M1-4 | 0.25 | 0.74 | 1330 | 65.0 | 0.74 |
| YE3-71M2-4 | 0.37 | 1.05 | 1330 | 67.0 | 0.75 |
| YE3-80M1-4 | 0.55 | 1.5 | 1390 | 71.0 | 0.75 |
| YE3-80M2-4 | 0.75 | 1.96 | 1390 | 73.0 | 0.76 |
| YE3-90S-4 | 1.1 | 2.76 | 1390 | 75.0 | 0.77 |
| YE3-90L-4 | 1.5 | 3.61 | 1390 | 78.0 | 0.79 |
| YE3-100L1-4 | 2.2 | 5.0 | 1410 | 80.0 | 0.81 |
| YE3-100L2-4 | 3 | 6.58 | 1410 | 82.0 | 0.82 |
| YE3-112M-4 | 4 | 8.59 | 1440 | 84.0 | 0.82 |
| YE3-132S-4 | 5.5 | 11.1 | 1440 | 85.0 | 0.83 |
| YE3-132M-4 | 7.5 | 14.9 | 1400 | 87.0 | 0.84 |
| 同步转速 Synchronous speed 1 000 r/min | |||||
| YE3-71M1-6 | 0.18 | 0.70 | 850 | 56.0 | 0.66 |
| YE3-71M2-6 | 0.25 | 0.90 | 850 | 59.0 | 0.68 |
| YE3-80M1-6 | 0.37 | 1.26 | 885 | 62.0 | 0.70 |
| YE3-80M2-6 | 0.55 | 1.73 | 885 | 65.0 | 0.72 |
| YE3-90S-6 | 0.75 | 2.22 | 910 | 69.0 | 0.72 |
| YE3-90L-6 | 1.1 | 3.1 | 910 | 72.0 | 0.73 |
| YE3-100L-6 | 1.5 | 3.83 | 920 | 76.0 | 0.75 |
| YE3-112M-6 | 2.2 | 5.42 | 935 | 79.0 | 0.76 |
| YE3-132S-6 | 3 | 7.10 | 960 | 81.0 | 0.76 |
| YE3-132M1-6 | 4 | 9.2 | 960 | 82.0 | 0.76 |
| YE3-132M2-6 | 5.5 | 12.2 | 965 | 84.0 | 0.77 |
