用途Usage
工矿、纺织、建筑业、可替代无油静音机，活塞机的所有用途。
Widely use for mineral industry,textile industry,construction industry,can replace all the usage of oiless silent air compressor and piston air compressor.
优 势 Advantage
- 比传统活塞空压机节能30% Energy-saving 30% than
- 宽电压使用 (150-250V) Stable use for 150-250V
- 启动电流低 Low starting current
- 噪音低，使用寿命长 Low noise with long lifetime
技术参数 Technical Data
| 型号
Model |
电压
Yoltage (v) |
排气量
Exhaust volume (m²/min) |
压力
Pressure (bar) |
转速
Speed (r/min】 |
容积
Yolume (L) |
功率
Power (kw) |
重量
Weight (kg) |
外型尺寸 Size
(mm) |
| Z5.5-10-0.8 | 220V50Hz | 0.8 | 10 | 3000 | 120 | 5.5 | 105 | 860*400*950 |
| Z7.5-10-1.1 | 380V50Hz | 1.1 | 10 | 3000 | 120 | 7.5 | 110 | 860*400*950 |
| ZW4.0-10-0.7 | 220V50Hz | 0.7 | 10 | 3000 | 200 | 4.0 | 145 | 1050*500*1050 |
| ZW 5.5-10-0.8 | 220V 50Hz | 0.8 | 10 | 3000 | 200 | 5.5 | 150 | 1050*500*1050 |
